This high-efficiency water pump adopts advanced hydraulic models and has excellent energy-saving performance. Its high flow and high head characteristics make it easier for drainage to face more complex situations. Widely used in mining development.
Technical SPECS
Our high vacuum system has patent certification.High-performance Oil-circulated Vacuum System with a maximum vacuum of -0.099MPa and 100 m³/h exhaust capacity. Built-in cooling system ensures stable operation without oil overheating. The air-water separator prevents water from entering the oil tank, maintaining efficiency.
| Machine performance | |
| Type | Trailor mounted，stationery，closed，open type |
| Max flow | 3000 m3/h |
| Max head | 100m |
| Suction height | 8m |
| Diesel engine parameters | |
| Brand recommended： | Cummins, Weichai, Yuchai |
| Power | >750kw |
| Speed | 1500rpm |
| Cooling method | Water cooled |
| Pump parameters | |
| Inlet | 16 inch |
| Outlet | 16 inch |
| Speed | 1500rpm |
| Pump case | Cast iron |
| Impeller | Cast iron/stainless steel |
| Shaft | Carbon steel/stainless steel |
| Max particle size: | 105mm |
| Accessories for option： | |
| Suction pipe，hose，quick connections，strainers，claps | |
MECHANICAL DIMENSIONS
PERFORMANCE CURVE
