Model# M4-150
Powered by a durable diesel engine, it supports continuous dry running to eliminate unexpected downtime risks. Integrated with a high-performance vacuum pump, it achieves a suction height exceeding 9 meters, expanding operational coverage.
Technical SPECS
Our high vacuum system has patent certification.High-performance Oil-circulated Vacuum System with a maximum vacuum of -0.099MPa and 100 m³/h exhaust capacity. Built-in cooling system ensures stable operation without oil overheating. The air-water separator prevents water from entering the oil tank, maintaining efficiency.
Performance
| Machine performance | |
| Type | Trailor mounted，stationery，closed，opentype |
| Max flow | 200 m3/h |
| Max Head | 150m |
| Suction height | 9m |
| Diesel engine parameters | |
| Brand recommended： | Cummins, Weichai, Yuchai |
| Power | >80kw |
| Speed | 2000~2900rpm |
| Cooling method | Water cooled |
| Pump parameters | |
| Inlet | 4 inch |
| Outlet | 4 inch |
| Speed | 2000~2900rpm |
| Pump case | Cast iron |
| Impeller | Cast iron/stainless steel |
| Shaft | Carbon steel/stainless steel |
| Max particle size: | 45mm |
| Accessories for option | |
| Suction pipe，hose，quickconnections，strainers，claps | |
MECHANICAL DIMENSIONS
PERFORMANCE CURVE
